1-33
HP 8719/20/22ES Specifications and Characteristics
Instrument Specifications
Test Port Input
Table 1-30 Test Port Input
HP 8719ES/20ES/22ES Test Port Input
Description Specification Supplemental Information
Frequency Range
HP 8719ES 0.05 to 13.51 GHz
HP 8720ES 0.05 to 20.05 GHz
HP 8722ES 0.05 to 40.05 GHz
Frequency Response (A, B, R)
Channel R
0.05 to 20.05 GHz ±1.5 dB, char.
20.05 to 32 GHz ±2.5 dB, char.
32 to 40 GHz +2.5 dB to −6 dB, char.
Channels A and B
50 to 500 MHz +2.5 dB to −28 dB, char.
0.5 to 20 GHz ±2.5 dB, char.
20 to 32 GHz ±3 dB, char.
32 to 40 GHz +3 dB to −6 dB, char.
Impedance
Standard 50 Ω, nominal.
Return Loss
Standard See uncorrected load match
chart.
Maximum Input Level
a
a. Maximum level at which no test port overload messages are seen.
Standard +10 dBm
Compression See dynamic accuracy chart.
Damage Level
Standard +30 dBm or > 40 Vdc, typ.
Option 012
test port +30 dBm or > 40 Vdc, typ.
direct sampler access +26 dBm or > 0 Vdc, typ.
