HP 8719/20/22ES Specifications and Characteristics
Instrument Specifications
Table 1-31 Test Port Input
HP 8719ES/20ES/22ES Test Port Input
Description Specification Supplemental Information
0.1 dB Compression (Option 012), direct receiver input
0.05 to 0.5 GHz −5 dBm, typ.
0.5 to 2 GHz −5 dBm, typ.
2 to 8 GHz −5 dBm, typ.
8 to 20 GHz −5 dBm, typ.
20 to 40 GHz −5 dBm, typ.
Average Noise Floor (Option 012) - 10 Hz IF BW
a
, direct receiver input
0.05 to 0.5 GHz −120 dBm, typ.
0.5 to 2 GHz −120 dBm, typ.
2 to 8 GHz −120 dBm, typ.
8 to 20 GHz −118 dBm, typ.
20 to 40 GHz −113 dBm, typ.
Frequency Offset Operation (Option 089)
b
Frequency Range 50 MHz to maximum frequency
Reference (R) Input Level
Maximum
HP 8719ES/20ES −7 dBm, typ.
HP 8722ES −12 dBm, typ.
Minimum
HP 8719ES/20ES/22ES −34 dBm, typ.
LO Spectral Purity and
Accuracy
Maximum Spurious Input < −25 dBc, typ.
Residual FM < 20 kHz, typ.
Frequency Accuracy ±16 MHz, typ.
a. The receiver noise floor is specified as the mean of the linear magnitude noise floor trace
over the specified frequency band.
b. The RF source characteristics in this mode are dependent on the stability of the external
LO source. The RF source tracks the LO to maintain a stable IF signal at the R channel
receiver input.
