1-35
HP 8719/20/22ES Specifications and Characteristics
Instrument Specifications
Table 1-32 Test Port Input
HP 8719/20/22ES Test Port Input
Description Supplemental Information
System Bandwidths
3000 Hz 10 Hz
Trace Noise
a
a. Trace noise is defined for a transmission measurement in CW mode, using a
“through” cable having 0 dB loss, with the source set to the lesser of the
maximum source output or to the maximum receiver input, and no
averaging. Trace noise is defined as the variation of a high level trace due to
noise.
Magnitude
0.05 GHz to 13.5 GHz < 0.03 dB rms, typ. < 0.003 dB rms, typ.
13.5 GHz to 20 GHz < 0.04 dB rms, typ. < 0.004 dB rms, typ.
20 GHz to 40 GHz < 0.15 dB rms, typ. < 0.015 dB rms, typ.
Phase
0.05 GHz to 13.5 GHz < 0.3° rms, typ. < 0.03° rms, typ.
13.5 GHz to 20 GHz < 0.4° rms, typ. < 0.04° rms, typ.
20 GHz to 40 GHz < 1.5° rms, typ. < 0.15° rms, typ.
Table 1-33 Test Port Input
HP 8719/20/22ES Test Port Input
Description Specification Supplemental
Information
Reference Level
Magnitude
Range ±500 dB
Resolution 0.001 dB
Phase
Range ±500°
Resolution 0.01°
