HP Agilent E8491A - Trigger Delays; Cooling; Power Supply Loading

Specifications 67Appendix A
Trigger Delays
Cooling
Power Supply Loading
Maximum delay from TTLTRG to
ECLTRG
60 ns
Maximum delay from ECLTRG to
TTLTRG
60 ns
Maximum delay from Trig In port
to ECLTRG or TTLTRG
300ns
Maximum delay from TTLTRG or
ECLTRG to Trig Out port
100 ns
Watts / slot 20W
P mm H
2
00.10
Air flow liters / s 2.0
I
PM
(amps) I
DM
(amps)
+5V 2.5 0.001
+12V 0.35 0.050
-12V 0.015 0.001
+24V 0.0 0.0
-24V 0.0 0.0
-5.2V 0.180 0.001
-2V 0.360 0.001
∆
