Appendix E
DC Power Supply
Replacing the DC Power Supply
182
6. Replace the DC connector cap located on the back side of your workstation’s DC power supply. See Figure
E-11.
Figure E-11 Replacing the DC Connector Cap
7. Complete the procedure in the section “Replacing the Front Bezel and Top Cover” found in this
chapter.
8. Connect and turn on the power to your system.
9. Determine that your DC power supply replacement was successful by observing to see if the
workstation’s LCD lights up and the CDE login screen appears in your workstation’s display. If
your workstation’s LCD does not light up and the CDE login screen does not appear, repeat this
procedure. If your workstation’s LCD still does not light up and the CDE login screen does not
appear, contact your local HP Support Representative.
DC Connector Cap
