DescriptionSpecification
• IEC 61000-4-2 Severity Level 3 for Electrostatic Discharge
• IEC 61000-4-3 Severity Level 3 for Radiated Fields
• IEC 61000-4-4 Severity Level 3 for Fast Transients
• IEC 61000-4-5 Severity Level 3 for Surge Voltage
• IEC 61000-4-6 Conducted Emissions
• IEC 61000-4-11 Voltage Variations
• EN 61000-4-12 Oscillatory Waves Immunity
• EN 61000-3-2 Limits for Harmonic Current Emissions
• EN 61000-3-3 JEIDA
EMC immunity
Nonblocking shared-memory switch
System architecture
FC-PH (FC Physical and Signalling Interface standard)
ANSI protocol
FC Class 2, Class 3, and Class F
Modes of operation
2112-byte
Maximum frame size
Less than 2 microseconds with no contention (destination port
is free)
Port-to-port latency
Weight and physical dimensions
nl
Table 19 lists physical properties.
Table 19 8Gb SAN Switch physical dimensions
MeasurementDimension
29.3 mm (1.15 in)
Height
208 mm (8.19 in)
Width
280 mm (11.02 in)
Depth
1.27 kg (2.8 lb)
Weight
SAN Switch technical specifications52
