6–12 437963-001 Service Reference Guide, dc5750
Removal and Replacement Procedures— Microtower (MT) Chassis
4. Before installing an expansion card, remove the expansion slot cover or the existing
expansion card.
✎
Before removing an installed expansion card, disconnect any cables that may be attached to the
expansion card.
a. If you are installing an expansion card in a vacant socket, remove the appropriate
expansion slot cover on the back of the chassis. Pull the slot cover straight up from the
socket then away from the inside of the chassis.
b. If removing a standard PCI expansion card, hold the card at each end, and carefully rock
it back and forth until the connectors pull free from the socket. Pull the expansion card
straight up from the socket 1 then away from the inside of the chassis 2 to release it
from the chassis frame. Be sure not to scrape the card against the other components.

HP COMPAQ DC5750 Specifications

General

Processor Speed	Up to 2.8 GHz
Chipset	ATI Radeon Xpress 1150
Memory	Up to 4 GB DDR2 SDRAM
Audio	Integrated High Definition Audio
Network	Integrated Broadcom NetXtreme Gigabit Ethernet
Processor	AMD Athlon 64 X2 / AMD Sempron
Storage	SATA Hard Drive
Optical Drive	DVD-ROM, DVD+/-RW
Operating System	Windows XP Professional
Form Factor	Small Form Factor or Microtower
USB Ports	8 USB 2.0 (2 front, 4 rear, 2 internal)
