HP COMPAQ DC5750 User Manual

Service Reference Guide, dc5750 437963-001 6–13
Removal and Replacement Procedures— Microtower (MT) Chassis
c. If removing a PCI Express x16 card, pull the retention arm on the back of the expansion
socket away from the card and carefully rock the card back and forth until the connectors
pull free from the socket. Pull the expansion card straight up from the socket then away
from the inside of the chassis to release it from the chassis frame. Be sure not to scrape
the card against the other components.
5. Store the removed card in anti-static packaging.
6. If not replacing the old expansion card with a new expansion card, install an expansion slot
cover to close the open slot. Insert the metal slot cover in the opened slot and slide the slot
cover lock down to secure the slot cover in place.
Ä
CAUTION: After removing an expansion card, you must replace it with a new card or expansion slot
cover for proper cooling of internal components during operation.

HP COMPAQ DC5750 Specifications

General

Processor Speed	Up to 2.8 GHz
Chipset	ATI Radeon Xpress 1150
Memory	Up to 4 GB DDR2 SDRAM
Audio	Integrated High Definition Audio
Network	Integrated Broadcom NetXtreme Gigabit Ethernet
Processor	AMD Athlon 64 X2 / AMD Sempron
Storage	SATA Hard Drive
Optical Drive	DVD-ROM, DVD+/-RW
Operating System	Windows XP Professional
Form Factor	Small Form Factor or Microtower
USB Ports	8 USB 2.0 (2 front, 4 rear, 2 internal)
