HP Compaq dc7100 DT Hardware Reference Guide

2–2 www.hp.com Hardware Reference Guide
Hardware Upgrades
✎
An optional cable lock may be used to secure the access panel,
preventing access to internal components including system memory,
the internal hard drive, and the MultiBay security catch. It may also
be used to secure the computer to a fixed object.
For more information on installing or removing these security
devices, refer to Appendix C, “Security Provisions.”
4. Remove the optional cable lock, if installed.
5. Position the computer on its side with the rubber pads on the
bottom. (If the computer is being used in the tower configuration,
remove the stand first. Refer to “Attaching and Removing the
Tower Stand” on page 2–7 for more information.)
6. Loosen the thumbscrew on the rear of the computer 1, slide the
access panel toward the rear of the computer 2, then lift it off.
Removing the Access Panel

HP Compaq dc7100 DT Specifications

General

Processor Speed	Up to 3.8 GHz
Chipset	Intel 915G
Memory	Up to 4 GB DDR2 SDRAM
Operating System	Windows XP Professional
Form Factor	Desktop
Processor	Intel Pentium 4
Storage	40 GB to 160 GB SATA
Graphics	ATI Radeon X300 SE
Optical Drive	DVD-ROM
Audio	Integrated audio
Network	Integrated Gigabit Ethernet
Expansion Slots	1 PCI Express x16
Ports	1 Parallel, 1 Serial, 2 PS/2, 1 VGA
