HP Compaq dc7100 DT Hardware Reference Guide

A–2 www.hp.com Hardware Reference Guide
Specifications
Vibration (random, Gs nominal)
Operating (10 to 300 Hz)
Nonoperating (10 to 500 Hz)
.25
.50
.25
.50
Power Supply
Operating Voltage Range
Rated Voltage Range*
Rated Line Frequency
90 to 264 VAC
100 to 240 VAC
50 to 60 Hz
90 to 264 VAC
100 to 240 VAC
50 to 60 Hz
Power Output 200 W 200 W
Rated Input Current (maximum)* 4 A
(@ 100 VAC)
2 A
(@ 200 VAC)
Heat Dissipation
Maximum
Typical (idle)
1050 BTU/hr
341 BTU/hr
265 kg-cal/hr
86 kg-cal/hr
*This system uses an active power factor corrected power supply. This allows the system
to pass the CE mark requirements for use in the countries of the European Union. The
active power factor corrected power supply also has the added benefit of not requiring
an input voltage range select switch.
Ultra-Slim Desktop (Continued)

HP Compaq dc7100 DT Specifications

General

Processor Speed	Up to 3.8 GHz
Chipset	Intel 915G
Memory	Up to 4 GB DDR2 SDRAM
Operating System	Windows XP Professional
Form Factor	Desktop
Processor	Intel Pentium 4
Storage	40 GB to 160 GB SATA
Graphics	ATI Radeon X300 SE
Optical Drive	DVD-ROM
Audio	Integrated audio
Network	Integrated Gigabit Ethernet
Expansion Slots	1 PCI Express x16
Ports	1 Parallel, 1 Serial, 2 PS/2, 1 VGA
