HP Compaq dc7100 DT Hardware Reference Guide

Hardware Reference Guide www.hp.com 1–3
Product Features
Rear Panel Components
1 Slot for Kensington Lock 8 Universal Serial Bus (USB) Connectors (6)
2 Screw hole for Universal Chassis Clamp
Lock
9 Monitor Connector
3 PCI Expansion Slot : Mouse Connector
4 Loop for Padlock ; Keyboard Connector
5 Access Panel Thumbscrew < Line-In Audio Connector
6 Power Cord Connector = Line-Out Audio Connector
7 Ethernet RJ-45 Connector
✎
Any USB device (including keyboard and mouse) can be connected to any USB connector.

HP Compaq dc7100 DT Specifications

General

Processor Speed	Up to 3.8 GHz
Chipset	Intel 915G
Memory	Up to 4 GB DDR2 SDRAM
Operating System	Windows XP Professional
Form Factor	Desktop
Processor	Intel Pentium 4
Storage	40 GB to 160 GB SATA
Graphics	ATI Radeon X300 SE
Optical Drive	DVD-ROM
Audio	Integrated audio
Network	Integrated Gigabit Ethernet
Expansion Slots	1 PCI Express x16
Ports	1 Parallel, 1 Serial, 2 PS/2, 1 VGA
