HP Compaq dc7100 DT Hardware Reference Guide

Hardware Reference Guide www.hp.com 2–9
Hardware Upgrades
To remove the stand from the computer:
1. Exit all software applications, shut down the operating system
software, turn off the computer and any external devices, then
disconnect the power cord from the power outlet.
2. Loosen the thumbscrew that secures the computer to the stand 1.
3. Slide the computer forward until it is disengaged from the hooks
on the front of the tower stand, then lift the computer up off the
stand 2.
Removing the Stand from the Computer

HP Compaq dc7100 DT Specifications

General

Processor Speed	Up to 3.8 GHz
Chipset	Intel 915G
Memory	Up to 4 GB DDR2 SDRAM
Operating System	Windows XP Professional
Form Factor	Desktop
Processor	Intel Pentium 4
Storage	40 GB to 160 GB SATA
Graphics	ATI Radeon X300 SE
Optical Drive	DVD-ROM
Audio	Integrated audio
Network	Integrated Gigabit Ethernet
Expansion Slots	1 PCI Express x16
Ports	1 Parallel, 1 Serial, 2 PS/2, 1 VGA
