HP Compaq dc7100 DT Hardware Reference Guide

B-2 www.hp.com Hardware Reference Guide
Battery Replacement
Ä
CAUTION: Static electricity can damage the electronic components of
the computer or optional equipment. Before beginning these procedures,
ensure that you are discharged of static electricity by briefly touching a
grounded metal object.
1. Use Computer Setup to disable the Smart Cover Sensor, if
necessary. Refer to the Computer Setup (F10) Utility Guide on
the Documentation CD for more information.
2. Remove the drive from the MultiBay. Refer to “Removing a
Drive from the MultiBay” on page 2–32 for more information.
3. Turn off the computer properly through the operating system,
then turn off any external devices. Disconnect the power cord
from the power outlet and disconnect any external devices.
4. Remove the computer access panel. Refer to “Removing and
Replacing the Access Panel” on page 2–1 for more information.
5. Remove the MultiBay daughter card by pulling it straight up out
of the computer 1.
6. Pull the power supply forward 2, then rotate the right side up 3.
7. Pull the power supply out of the computer.
Removing the Power Supply

HP Compaq dc7100 DT Specifications

General

Processor Speed	Up to 3.8 GHz
Chipset	Intel 915G
Memory	Up to 4 GB DDR2 SDRAM
Operating System	Windows XP Professional
Form Factor	Desktop
Processor	Intel Pentium 4
Storage	40 GB to 160 GB SATA
Graphics	ATI Radeon X300 SE
Optical Drive	DVD-ROM
Audio	Integrated audio
Network	Integrated Gigabit Ethernet
Expansion Slots	1 PCI Express x16
Ports	1 Parallel, 1 Serial, 2 PS/2, 1 VGA
