HP Compaq dc7100 MT User Manual

2–20 www.hp.com Hardware Reference Guide
Hardware Upgrades
10. To install a new expansion card, slide the bracket on the end of
the card down into the slot on the back of the chassis and press
the card down firmly into the socket on the system board.
Installing an Expansion Card
✎
When you install an expansion card, make sure you press firmly on
the card so that the whole connector seats properly in the expansion
card socket.
11. Close the expansion card retention latch, making sure that it
snaps firmly into place.
12. Connect external cables to the installed card, if needed. Connect
internal cables to the system board, if needed.
13. Replace the computer access panel.
14. If you normally lock the Smart Cover Lock, use Computer Setup
to relock the lock and enable the Smart Cover Sensor.
15. Reconfigure the computer, if necessary. Refer to the Computer
Setup (F10) Utility Guide on the Documentation CD for
instructions about using Computer Setup.

HP Compaq dc7100 MT Specifications

General

Graphics	Integrated Intel Graphics Media Accelerator 900
Network	Integrated Broadcom NetXtreme Gigabit Ethernet
Operating System	Windows XP Professional
Form Factor	Microtower
Processor	Intel Pentium 4
Chipset	Intel 915G Express
Memory	Up to 4 GB DDR2 SDRAM
Storage	40 GB to 160 GB SATA
Optical Drive	DVD-ROM
Ports	USB 2.0, serial, parallel, audio in/out
Expansion Slots	1 PCI Express x16
Audio	Integrated AC'97 audio
