6–16 Maintenance and Service Guide
Removal and Replacement Procedures
6.9 Keyboard Cover
1. Prepare the notebook for disassembly (Section 6.3).
2. Position the notebook with the front toward you.
3. Remove the two T8M2.0×18.0 screws that secure the
keyboard cover to the notebook.
Removing the Keyboard Cover Screws
Keyboard Cover Spare Part Number Information
Keyboard cover 383519-001
To Next Page
