6–32 Maintenance and Service Guide
Removal and Replacement Procedures
6.16 Display Assembly
1. Prepare the notebook for disassembly (Section 6.3).
2. Remove the keyboard cover (Section 6.9).
3. Remove the keyboard (Section 6.10).
4. Close the notebook.
5. Turn the notebook upside down with the rear panel
toward you.
Display Assembly Spare Part Number Information
12.1-inch, XGA, TFT display assembly (includes wireless
antenna boards and cables)
383548-001
Display Hinge Kit 383530-001
LCD rubber pad kit, with screws 383546-001
To Next Page
