6–46 Maintenance and Service Guide
Removal and Replacement Procedures
6.19 TouchPad
1. Prepare the notebook for disassembly (Section 6.3)
and remove the following components:
a. Hard drive (Section 6.4)
b. Keyboard cover (Section 6.9)
c. Keyboard (Section 6.10)
d. Display assembly (Section 6.16)
e. Button board (Section 6.17)
f. Top cover (Section 6.18)
2. Turn the top cover upside down with the front toward you.
TouchPad Spare Part Number Information
TouchPad 383562-001
TouchPad cable (included in the Cable Kit, spare part number 383516-001)
