Removal and Replacement Procedures
Maintenance and Service Guide 6–45
6. Disconnect the TouchPad cable from the system board 1.
7. Lift the rear edge of the top cover 2 until it disengages from
the base enclosure.
8. Lift the top cover straight up 3 and remove it.
Removing the Top Cover
Reverse the above procedure to install the top cover.
