Product Description
Maintenance and Service Guide 1–9
Table 1-2
Right-Side Components
Item Component Function
1Audio-out
(headphone) jack
Connects an optional headphone or
powered stereo speakers. Also connects
the audio function of an audio/video device,
such as a television or VCR.
2 Audio-in (microphone)
jack
Connects an optional monaural (single
sound channel) or stereo (dual sound
channel) microphone.
3 Powered USB port Connects USB 1.1- or 2.0-compliant
devices to the notebook using a standard
USB cable, or connects an optional external
MultiBay or external MultiBay II to
the notebook. This USB port is a powered
port that can be used without external
power.
4 PC Card slot eject
button
Ejects PC Cards from the PC Card slot.
5 PC Card slot Supports optional Type I, Type II, 32-bit
(CardBus), or 16-bit PC Cards.
6 SD Card slot Accepts SD (Secure Digital) Memory Cards
or MultiMediaCards.
