HP Compaq nc8430

A–22 Maintenance and Service Guide
Screw Listing
Torx8 T8M2.5×6.0 Screw Locations
Table A-14
Torx8 T8M2.5×6.0 Screw
Color Qty. Length Thread
Head
Width
Black 4 6.0 mm 2.5 mm 5.0 mm
Where used:
4 screws that secure the thermal plate to the computer (documented in
Section 5.10)
mm
