5–8 Maintenance and Service Guide
Removal and Replacement Procedures
2. Loosen the two Phillips PM2.0×5.0 screws 1 that secure the
hard drive cover to the computer.
3. Lift the left side of the hard drive cover 2 and swing it to
the right.
4. Remove the hard drive cover.
✎
The hard drive cover is included in the Plastics Kit, spare part
number 417527-001.
Removing the Hard Drive Cover
