Removal and Replacement Procedures
Maintenance and Service Guide 5–35
5.16 RTC Battery
The RTC battery is included with each system board spare part
kit.
1. Prepare the computer for disassembly (Section 5.3).
2. Release the keyboard (Section 5.9).
3. Remove the RTC battery from the clip in the top cover.
Removing the RTC Battery
Reverse the above procedure to install an RTC battery.
