Removal and Replacement Procedures

Maintenance and Service Guide 5–3

5.2 Disassembly Sequence Chart

Use the chart below to determine the section number to be

referenced when removing computer components.

Disassembly Sequence Chart

Section Description

# of s Removed

5.3 Preparing the Computer for

Disassembly

Battery

5.4 Hard Drive 2 loosened to remove the

hard drive cover

1 loosened to remove the

hard drive

4 to disassemble hard drive

5.5 Computer Feet 0

5.6 Optical Drive 1 to remove the optical drive

2 to remove the optical drive

bracket

5.7 External Memory Module 1 loosened to remove the

memory module

compartment cover

5.8 Bluetooth Module 1 loosened to remove the

Bluetooth module cover

2 removed to remove

Bluetooth module

5.9 Keyboard 2

5.10 Thermal Plate 4

5.11 Fan Assembly 2 loosened

5.12 Heat Sink 4 loosened
