1–10 Maintenance and Service Guide
Product Description
The external components on the rear panel of the computer are
shown below and described in Table 1-3.
Rear Panel Components
Table 1-3
Rear Panel Components
Item Component Function
1 Battery bay Holds a battery.
2 Smart adapter power
connector
Connects an AC adapter or an optional
power adapter.
3 External monitor port Connects an optional VGA external
monitor or projector.
