HP Compaq NX7300 User Manual

Product Description
Maintenance and Service Guide 1–7
1.4 External Components
The external components on the front of the computer are shown
below and described in Table 1-1.
Front Components
Table 1-1
Front Components
Item Component Function
1 Wireless light On: An integrated wireless device, such as
a wireless local area network (LAN) device
and/or a Bluetooth® device, is turned on.
2Power light ■ On: The computer is on.
■ Blinking: The computer is in standby.
■ Blinking rapidly: An HP Smart AC
Adapter with a higher power rating
should be connected.
■ Off: The computer is off or in hibernation.

HP Compaq NX7300 Specifications

General

Graphics	Intel Graphics Media Accelerator 950
Operating System	Windows XP Professional
Wireless	802.11a/b/g
RAM	512 MB DDR2 SDRAM
Storage	80GB or 120GB HDD
Display	15.4 inch WXGA (1280x800)
Optical Drive	DVD-ROM
LAN	10/100/1000 Ethernet
Ports	3 x USB 2.0, VGA, RJ-11, RJ-45, headphone, microphone
Battery	6-cell Lithium-Ion
Weight	2.7 kg
