5–22 Maintenance and Service Guide
Removal and Replacement Procedures
8. Release the zero insertion force (ZIF) connector 1 to which
the keyboard cable is connected and disconnect the keyboard
cable 2 from the system board.
Disconnecting the Keyboard Cable
9. Remove the keyboard.
Reverse the above procedure to install the keyboard.
