5–44 Maintenance and Service Guide
Removal and Replacement Procedures
3. Remove the two rubber screw covers 1 and the twelve Torx8
T8M2.5×10.0 screws 2 that secure the top cover to the
computer. Note that the defeatured model uses two fewer
screws.
✎
The rubber screw covers are available in the Screw Kit, spare
part number 417526-001.
Removing the Top Cover Screws, Part 1 (select models only)
