6–4 Maintenance and Service Guide
Specifications
Table 6-3
15.4.0-inch, WXGA+
Dimensions
Height
Width
Diagonal
20.7 cm
33.1 cm
39.1 cm
8.1 in
13.0 in
15.4 in
Number of colors Up to 16.8 million
Contrast ratio 200:1
Brightness 180 nits typical
Pixel resolution
Pitch
Format
Configuration
0.279 × 0.279 mm
1280 × 800
RGB vertical stripe
Backlight CCFT
Character display 80 × 25
Total power consumption 5.5 W
Viewing angle +/-65° horizontal, +/-50° vertical typical
