Screw Listing
Maintenance and Service Guide A–11
Torx8 T8M2.5×10.0 Screw Locations
Table A-7
Torx8 T8M2.5×10.0 Screw
Color Qty. Length Thread
Head
Width
Black 20/18* 10.0 mm 2.5 mm 5.0 mm
Where used:
1 Two screws that secure the keyboard to the computer (documented in
Section 5.9)
2 Four screws that secure the display assembly to the computer (documented
in Section 5.18)
* 18 screws on defeatured model
mm
