HP Compaq NX7300 - Phillips PM2.5×7.0 Captive Screw

A–16 Maintenance and Service Guide
Screw Listing
Phillips PM2.5×7.0 Captive Screw Locations
Table A-10
Phillips PM2.5×7.0 Captive Screw
Color Qty. Length Thread
Head
Width
Silver 2 7.0 mm 2.5 mm 5.0 mm
Where used:
2 captive screws that secure the fan assembly to the computer (documented in
Section 5.11)
mm
