5–32 Maintenance and Service Guide
Removal and Replacement Procedures
Ä
CAUTION: Make sure the display is supported when removing the
following screws. The display is secured to the computer only by
these screws and will fall if not supported during screw removal.
9. Remove the four TM2.5 × 9.0 screws
1
that secure the
display to the base enclosure (Figure 5-24).
10. Remove the display from the base enclosure
2
.
Figure 5-24. Removing the Display
