HPE Aruba Networking CX 6300 Switch Series | Installation and Getting Started Guide 31
When using a DC power supply, the unit should be installed in a restricted access location. Only trained and
qualified personnel should be allowed to install, replace, or service this equipment.
Ensure that the DCcable is disconnected from the DC power source before proceeding with the installation.
1. Ensure that the correct DCcable is used for the power supply being installed.
a. Included DCcable HPPN 5400-3519 for JL758A (8AWG cable with Ring lugs).
b. Included DCcable HPPN5400-3521 for JL757A (12AWG cable with Ring lugs).
2. Organize and tie the cable. The DCcable needs to be strain-relieved by tying securely it to a fixed structure
or rack. NOTE: Do not tie the DCcables to the power supply fan handle as it is not designed to take the
weight of the cables.
Ensure that the DCcable does not obstruct or block the air flow of the power supply fan.
