2 Technical specifications
Physical specifications
8.8 cm (3.47 in)Height (2U)
Dimensions 45.0 cm (17.99 in)Width
56.7 cm (22.3 in)Depth
No disk drives: 17.2 kg (38 lb)
Weight Fully populated with SFF disk drives: 24.9 kg (54.90 lb)
Fully populated with LFF disk drives: 27.2 kg (59.97 lb)
250 connect/disconnect cycles (for external, internal, and cable Mini
SAS connectors)
Mini SAS connector life expectancy
Power and environmental specifications
10°C to 35°C (50°F to 95°F) Maximum rate
of change is 10ºC/Hr (18ºF/Hr)
Operating
Temperature range (Temperature ratings
shown are for sea level. An altitude rating
of 1°C per 300 m (1.8°F per 1,000 ft) to
3048 m (10,000 ft) is applicable. The upper
limit might be limited by the type and number
of options installed.)
–40°C to 66°C (–40°F to 150°F) Maximum
rate of change is 20ºC/Hr (36ºF/Hr)
Shipping
10% to 90% relative humidity (Rh) 28ºC
(82.4ºF) Maximum wet bulb temperature non-
condensing
Operating
Relative humidity (Non-operating maximum
humidity of 95% is based on a temperature
of 45°C (113°F). Altitude maximum for stor-
age corresponds to a pressure minimum of
70 KPa.)
5% to 95% relative humidity (Rh)Non-operating
3048 m (10,000 ft) This value might be lim-
ited by the type and number of options in-
stalled.
Operating
Altitude (Maximum allowable altitude change
rate is 457 m/min (1500 ft/min))
9144 m (30,000 ft)Non-operating
100 to 240 VACInput voltage
Input power (Input Power and Heat Dissipa-
tion specifications are maximum values and
apply to worst-case conditions at full rated
power supply load. The power/heat dissipa-
tion for your installation will vary depending
on the equipment configuration.)
50 to 60 HzInput frequency
2.68 A at 115 VAC typical, 4 A maximumInput current
300 W
Input power
(max)
D2600/D2700 Disk Enclosure User Guide 19
