Small Form Factor disk enclosure chassis
Front view
3. UID push button and LED1. Rack-mounting thumbscrews
4. Enclosure status LEDs2. Disk drive in bay 9
Drive bay numbering
Disk drives mount in bays on the front of the enclosure. Bays are numbered sequentially from top to
bottom and left to right. Bay numbers are indicated on the left side of each drive bay.
Rear view
7. UID push button and LED4. I/O module A1. Power supply 1
8. Enclosure status LEDs5. I/O module B2. Power supply 2
9. Power push button and LED6. Fan 23. Fan 1
Hardware8
