1 Hardware
Overview
6Gb SAS disk enclosures are available in two models:
Small Form Factor (SFF): Supports 25 SFF (2.5 inch) disk drives
Large Form Factor (LFF): Supports 12 LFF (3.5 inch) disk drives
Large Form Factor disk enclosureSmall Form Factor disk enclosure
NOTE:
Depending on your disk enclosure model and controller installation environment, one or more disk
enclosures can be cascaded from the disk enclosure that is connected to the controller. For more
information, see the QuickSpecs for the disk enclosure, available on the D2000 website:
http://www.hp.com/go/D2000.
The enclosure and its components are detailed in the following sections:
Small Form Factor disk enclosure chassis, page 8
Large Form Factor disk enclosure chassis, page 9
Disk drives, page 10
Front status and UID module, page 11
Power supply module, page 12
Fan module, page 13
I/O module, page 14
Rear power and UID module, page 16
SAS cables, page 17
D2600/D2700 Disk Enclosure User Guide 7
