Page #10 background imageLoading...
Page #10 background image
Component identification 10
Item Description Status
1 NIC link/activity LED Green = Network link
Flashing green = Network link and
activity
Off = No link to network. If the power is
off, view the rear panel RJ-45 LEDs for
status ("Rear panel LEDs and buttons" on
page 12)
2 Power cap
To determine Power cap status, see
"Systems Insight Display LED
combinations (on page 10)."
3 AMP status Green = AMP mode enabled
Amber = Failover
Flashing amber = invalid configuration
Off = AMP modes disabled
All other LEDs Off = Normal
Amber = Failure
For detailed information on the
activation of these LEDs, see "Systems
Insight Display LED combinations (on
page 10)."
Systems Insight Display LED combinations
When the health LED on the front panel illuminates either amber or red, the server is experiencing a
health event. Combinations of illuminated Systems Insight Display LEDs, the system power LED, and the
health LED indicate system status.
Systems Insight
Display LED and color
Health LED
System power
LED
Status
Processor (amber) Red Amber
One or more of the following conditions
may exist:
Processor in socket X has failed.
Processor X is not installed in the
socket.
Processor X is unsupported.
ROM detects a failed processor during
POST
Processor (amber) Amber Green
Processor in socket X is in a pre-failure
condition.
DIMM (amber) Red Green One or more DIMMs have failed.
DIMM (amber) Amber Green DIMM in slot X is in a pre-failure condition.
Overtemperature
(amber)
Amber Green
The Health Driver has detected a
cautionary temperature level.
Overtemperature
(amber)
Red Amber
The server has detected a hardware critical
temperature level.
Fan (amber) Amber Green One fan has failed or has been removed.
