Removing the monitor stand

You can remove the monitor panel from the stand to install the monitor panel on a wall, a swing arm, or other

mounting xture.

CAUTION: Before beginning to disassemble the monitor, be sure that the monitor is turned o and all cables

are disconnected.

1. Disconnect and remove all cables from the monitor.

2. Position the monitor facedown on a at surface covered by a clean, dry cloth.

3. Push up on the latch near the bottom center of the monitor (1).

4. Swing the bottom of the stand up until the mounting plate clears the recess in the panel (2).

5. Slide the stand out of the recess.

16 Chapter 1 Getting Started
