68.5 cm/27-inch model
Display, wide-screen
Type
68.5 cm
IPS
27-inch
Viewable image size 68.5 cm diagonal 27-inch diagonal
Maximum weight (unpacked) 7.9 kg 17.4 lbs
Dimensions (include base)
Height (highest position)
Height (lowest position)
Depth
Width
53.39 cm
38.39 cm
21.4 cm
61.094 cm
21.02 inches
15.11 inches
8.43 inches
24.1 inches
Tilt -5° to 22°
Swivel 45° ± 2°
Maximum graphic resolution 1920 x 1080
Optimum graphic resolution 1920 x 1080
Environmental requirements temperature
Operating temperature
Storage temperature
Storage humidity
Operating humidity
5 to 35° C
-20 to 60° C
41 to 95° F
-4 to 140° F
5% to 95% (non-condensing)
20% to 80% (non-condensing)
Power source 100–240 VAC 50/60 Hz
Input terminal One Type C connector, HDMI connector, one
DisplayPort connector, one VGA connector
Preset display resolutions
The display resolutions listed below are the most commonly used modes and are set as factory defaults. The
monitor automatically recognizes these preset modes and they will appear properly sized and centered on the
screen.
60.5 cm/23.8-inch and 68.5 cm/27-inch models
Preset Pixel Format Horz Freq (kHz) Vert Freq (Hz)
1 640 × 480 31.469 59.940
2 720 × 400 31.469 70.087
3 800 × 600 37.879 60.317
4 1024 × 768 48.363 60.004
5 1280 × 720 45.00 60.000
6 1280 × 800 49.702 59.810
30 Appendix A Technical specications
