HP E27k G5 User Manual

7
to 65 W of power to a device. Power delivery outputs are
20V/3.25A, 15V/4.33A, 12V/5A, 9V/3A, 5V/3A to achieve a 65 W
output.
Connecting a USB T
ype-C cable from a source device to this
port on the monitor enables USB ports on the monitor.
(7)
RJ
-45 (network)
jack
Network (RJ-45) data rate via USB Type-C max speed is 1000
Mbps
Green (right): The network is connected.
Amber (left): Activity is occurring on the network.
NOTE: Supports Wake on Lan (WOL) In-band, Mac Address
Passthrough (MAPT) in-band (HP models only), and PXE boot.
The functionality may vary with PC settings.
NOTE:
This network port is fully energy efficient according to IEEE
standards (IEEE 802.3az
-2010) as long as all connected devices
support this feature.
(8)
USB Type
-A port
Connects a USB device to transfer data.
(9)
USB Type
-C
port
(downstream)
Connects a USB Type-C cable to a peripheral USB device,
provides data transfer, even when the monitor is in Sleep
mode or DC off with OSD Performance mode on. This port
charges most devices (15 W), such as a smart phone or a
tablet.
NOTE:
Cables or adapters may be required (purchased
separately).
(10)
USB Type
-A port
(1), USB Type
-A
port with
battery fast
-
charging 1.2 (1)
USB port: Connects a USB device, provides data transfer, and
(for select products) charges small devices (such as a
smartphone) when the computer is on or in Sleep mode.
USB port with battery fast-charging 1.2 (5 V × 1.5 A = 7.5 W):
Connects a USB device, provides high-speed data transfer,
and charges small devices (such as a smartphone), even
when the monitor is DC off with OSD performance mode on.
NOTE:
Use a standard USB Type-A charging cable or cable
adapter (purchased separately) when charging a small
external device.

HP E27k G5 Specifications

General

Color depth	10 bit
Color gamut	99 %
Pixel pitch	0.15 x 0.15 mm
Screen shape	Flat
Display diagonal	27 \
Surface hardness	3H
Anti-glare screen	Yes
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Contrast ratio (dynamic)	8000000:1
Display number of colors	1.07 billion colors
Display diagonal (metric)	68.6 cm
Digital vertical frequency	30 - 60 Hz
Digital horizontal frequency	30 - 135 kHz
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 720 x 480, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1440 x 900 (WXGA+), 1600 x 1200, 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 3840 x 2160
DisplayPort version	1.4
USB upstream port type	USB Type-C
USB Power Delivery up to	65 W
USB Type-A downstream ports quantity	3
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	190 W
Power consumption (standby)	0.5 W
Power consumption (typical)	29 W
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	446 mm
Package width	699 mm
Package height	160 mm
Package weight	10100 g
Pivot angle	0 - 90 °
Tilt angle range	-5 - 20 °
Height adjustment	150 mm
Panel mounting interface	100 x 100 mm
Cables included	AC, USB Type-C to USB Type-C
Product color	Black, Silver
Country of origin	China
Market positioning	Business
RMS rated power	6 W
Number of speakers	2
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	227.3 mm
Width (with stand)	613.4 mm
Height (with stand)	547 mm
Weight (with stand)	10000 g
Depth (without stand)	47 mm
Height (without stand)	364.6 mm
