HP E27k G5 User Manual

2 Monitor features
This chapter provides an overview of the monitor’s features.
Features
Depending on the model, your monitor might include the following features:
● 68.47 cm (27 inch) diagonal viewable area with 3842 × 2160 resolution, plus full screen
support for lower resolutions
● USB Type-C port for docking an HP notebook or HP desktop mini
● Single power button on the monitor to turn the monitor and docked notebook on and
off
● One High-Definition Multimedia Interface (HDMI) 2.0 video input
● RJ-45 (network) jack
● Non-glare panel with an LED backlight
● Wide viewing angle to allow viewing from a sitting or standing position, or when moving
from side to side
● On-screen display (OSD) adjustments in several languages for easy setup and screen
optimization
● Plug and Play capability if supported by your operating system
● Tilt, swivel, and height adjustment capabilities
● Pivot capability to rotate the monitor head from landscape to portrait orientation
● Removable stand (optional) for flexible monitor head mounting solutions
● DisplayPort video input
● USB hub with one USB Type-C port and 3 USB Type-A ports that connect to USB devices
● Up to 65 W power delivery through USB Type-C (5 A) cable
● HDCP (High-bandwidth Digital Content Protection) used on all digital inputs
● Power Saver mode to meet requirements for reduced power consumption
● Security cable slot on the rear of the monitor for an optional security cable
NOTE: For safety and regulatory information, refer to the Product Notices provided in your
documentation kit. To access the latest user guides or manuals for your product, go to
http://www.hp.com/support and follow the instructions to find your product. Then select
Manuals.

HP E27k G5 Specifications

General

Color depth	10 bit
Color gamut	99 %
Pixel pitch	0.15 x 0.15 mm
Screen shape	Flat
Display diagonal	27 \
Surface hardness	3H
Anti-glare screen	Yes
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Contrast ratio (dynamic)	8000000:1
Display number of colors	1.07 billion colors
Display diagonal (metric)	68.6 cm
Digital vertical frequency	30 - 60 Hz
Digital horizontal frequency	30 - 135 kHz
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 720 x 480, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1440 x 900 (WXGA+), 1600 x 1200, 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 3840 x 2160
DisplayPort version	1.4
USB upstream port type	USB Type-C
USB Power Delivery up to	65 W
USB Type-A downstream ports quantity	3
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	190 W
Power consumption (standby)	0.5 W
Power consumption (typical)	29 W
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	446 mm
Package width	699 mm
Package height	160 mm
Package weight	10100 g
Pivot angle	0 - 90 °
Tilt angle range	-5 - 20 °
Height adjustment	150 mm
Panel mounting interface	100 x 100 mm
Cables included	AC, USB Type-C to USB Type-C
Product color	Black, Silver
Country of origin	China
Market positioning	Business
RMS rated power	6 W
Number of speakers	2
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	227.3 mm
Width (with stand)	613.4 mm
Height (with stand)	547 mm
Weight (with stand)	10000 g
Depth (without stand)	47 mm
Height (without stand)	364.6 mm
