HP Elite x2 1012 G2

i. WWAN module (see WWAN or GPS module (select products only) on page 40)
j. Webcam (see Webcam on page 42)
Remove the microphone board:
CAUTION: Use care to prevent damaging the zero-insertion force (ZIF) connector and ribbon cable.
▲
Disconnect the microphone cable from the system board(1), remove the metal plate (2), and then lift
the microphone board to remove it (3).
Reverse this procedures to replace the microphone board.
44 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
