HP Elite x2 1012 G2 User Manual

Speakers
Description Spare part number
Speakers 925445-001
IMPORTANT: Make special note of each screw and screw lock size and location during removal and
replacement
Before removing the speakers, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the following components:
a. Kickstand (select products only) (see Kickstand on page 26)
b. Back cover (see Back cover on page 29)
c. Display panel (see Display panel on page 30)
d. Battery (see Battery on page 32)
e. Hall sensor board (see Hall sensor board on page 34)
f. Kickstand hinges (see Kickstand hinges on page 35)
g. Solid-state drive (see Solid-state drive on page 36)
h. WLAN module (see WLAN module on page 38)
i. WWAN module (see WWAN or GPS module (select products only) on page 40)
j. Webcam (see Webcam on page 42)
k. Microphone board (see Microphone board on page 43)
l. Rear webcam (see Rear webcam on page 45)
m. System board (see System board on page 47)
n. POGO connector (see POGO connector on page 48)
o. Fan (see Fan on page 49)
p. Fingerprint reader board (see Fingerprint reader board on page 51)
Remove the speakers:
1. Lift the right speaker (1), and then left the right speaker (2)r.
Component replacement procedures 53

HP Elite x2 1012 G2 Specifications

General

Form factor	Convertible (Detachable)
Product type	Hybrid (2-in-1)
Product color	Silver
Country of origin	China
Display diagonal	12.3 \
Touch technology	Multi-touch
Display resolution	2736 x 1824 pixels
Native aspect ratio	3:2
Bus type	OPI
Stepping	H0
Tjunction	100 °C
Processor cache	4 MB
Processor cores	2
System bus rate	4 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-7600 Mobile Series
Processor socket	BGA 1356
Processor threads	4
Processor codename	Kaby Lake
Configurable TDP-up	25 W
Processor frequency	2.8 GHz
Processor cache type	Smart Cache
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.9 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x2, 1x4, 2x2, 2x1, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.9 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Internal memory	8 GB
Memory clock speed	1866 MHz
Internal memory type	LPDDR3-SDRAM
Maximum internal memory	16 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	NVMe 3.0, PCI Express
Storage media	SSD
SSD form factor	M.2
Total storage capacity	512 GB
Compatible memory cards	MicroSD (TransFlash)
Number of SSDs installed	1
On-board graphics card ID	0x5916
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 620
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	32 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Battery capacity	47 Wh
Battery life (max)	10 h
Video capturing speed	30 fps
Front camera resolution	1920 x 1080 pixels
Front camera signal format	1080p
Rear camera resolution (numeric)	8 MP
Front camera resolution (numeric)	5 MP
AC adapter power	65 W
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Mobile network generation	4G
Sustainability certificates	ENERGY STAR
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Pointing device	Clickpad
Processor code	SR33Z
Processor ARK ID	97466
Processor package size	42 x 24 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Height	14.6 mm
Weight	1150 g
Depth (tablet mode)	219.7 mm
Width (tablet mode)	300 mm
Height (tablet mode)	9.1 mm
Weight (tablet mode)	800 g
