HP Elite x2 1012 G2 User Manual

8 Computer Setup (BIOS), TPM, and HP Sure
Start
Using Computer Setup
Computer Setup, or Basic Input/Output System (BIOS), controls communication between all the input and
output devices on the system (such as disk drives, display, keyboard, mouse, and printer). Computer Setup
includes settings for the types of devices installed, the startup sequence of the computer, and the amount of
system and extended memory.
NOTE: Use extreme care when making changes in Computer Setup. Errors can prevent the computer from
operating properly.
Starting Computer Setup
▲
Turn on or restart the computer, and when the HP logo appears, press f10 to enter Computer Setup.
Using a USB keyboard or USB mouse to start Computer Setup (BIOS)
You can start Computer Setup by using a keyboard or mouse connected to a USB port, but you must rst
disable FastBoot.
1. Turn on or restart the computer, and when the HP logo appears, press f9 to enter the Boot Device
Options menu.
2. Clear the check box for Fast Boot.
3. To save your changes and exit, select the Save icon in the lower-right corner of the screen, and then
follow the on-screen instructions.
– or –
Select Main, select Save Changes and Exit, and then press enter.
Your changes go into eect when the computer restarts.
Navigating and selecting in Computer Setup
●
To select a menu or a menu item, use the tab key and the keyboard arrow keys and then press enter, or
use a pointing device to select the item.
●
To scroll up and down, select the up arrow or the down arrow in the upper-right corner of the screen, or
use the up arrow key or the down arrow key on the keyboard.
●
To close open dialog boxes and return to the main Computer Setup screen, press esc, and then follow
the on-screen instructions.
62 Chapter 8 Computer Setup (BIOS), TPM, and HP Sure Start

HP Elite x2 1012 G2 Specifications

General

Form factor	Convertible (Detachable)
Product type	Hybrid (2-in-1)
Product color	Silver
Country of origin	China
Display diagonal	12.3 \
Touch technology	Multi-touch
Display resolution	2736 x 1824 pixels
Native aspect ratio	3:2
Bus type	OPI
Stepping	H0
Tjunction	100 °C
Processor cache	4 MB
Processor cores	2
System bus rate	4 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-7600 Mobile Series
Processor socket	BGA 1356
Processor threads	4
Processor codename	Kaby Lake
Configurable TDP-up	25 W
Processor frequency	2.8 GHz
Processor cache type	Smart Cache
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.9 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x2, 1x4, 2x2, 2x1, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.9 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Internal memory	8 GB
Memory clock speed	1866 MHz
Internal memory type	LPDDR3-SDRAM
Maximum internal memory	16 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	NVMe 3.0, PCI Express
Storage media	SSD
SSD form factor	M.2
Total storage capacity	512 GB
Compatible memory cards	MicroSD (TransFlash)
Number of SSDs installed	1
On-board graphics card ID	0x5916
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 620
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	32 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Battery capacity	47 Wh
Battery life (max)	10 h
Video capturing speed	30 fps
Front camera resolution	1920 x 1080 pixels
Front camera signal format	1080p
Rear camera resolution (numeric)	8 MP
Front camera resolution (numeric)	5 MP
AC adapter power	65 W
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Mobile network generation	4G
Sustainability certificates	ENERGY STAR
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Pointing device	Clickpad
Processor code	SR33Z
Processor ARK ID	97466
Processor package size	42 x 24 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Height	14.6 mm
Weight	1150 g
Depth (tablet mode)	219.7 mm
Width (tablet mode)	300 mm
Height (tablet mode)	9.1 mm
Weight (tablet mode)	800 g
