2. Use a tool (2) to release the battery from the computer (3).
Reverse this procedure to install the RTC battery.
Speakers
To remove the speakers, use this procedure and illustration.
Table 6-3 Speaker description and part number
Description Spare part number
Speaker Kit M73520-001
Before removing the speakers, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 32).
2. Remove the bottom cover (see Bottom cover on page 32).
3. Disconnect the battery cable from the system board (see Battery on page 42).
Remove the speakers:
1. Disconnect the speaker cable from the system board (1).
2. Remove the cable between the speakers from the clips along the bottom of the battery (2).
Component replacement procedures 45
