Diagnostics menu
Select To do this
System Diagnostics menu
●
F1 System Information—Displays the following
information:
◦
Identification information for the computer and the
batteries in the system.
◦
Specification information for the processor, cache
and memory size, system ROM, video revision, and
keyboard controller version.
●
F2 Start-up Test—Verifies the system components
needed for starting the computer.
●
F3 Run-In Test—Runs a comprehensive check on
system memory.
●
F4 Hard Disk Test—Runs a comprehensive self-test on
any hard drive in the system.
●
F5 Error Log—Displays a log file if any errors have
occurred.
Computer Setup menus 95

Table of Contents

Other manuals for HP EliteBook 8730w

Preview: Brochure & Specs
Brochure & Specs8 pages
Preview: Quickspecs
Quickspecs46 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 8730w and is the answer not in the manual?

HP EliteBook 8730w Specifications

HP EliteBook 8530w Mobile Workstation

Processor and Chipset IconProcessor and Chipset
processorIntel Core Duo (up to 3.06 GHz, up to 6 MB L2 cache), Intel Core Quad-Core (up to 2.53 GHz, up to 12 MB L2 cache)
chipsetMobile Intel PM45 Express Chipset (Discrete)
Graphics IconGraphics
graphicsATI Mobility FireGL V5700 with 256MB of video memory, NVIDIA Quadro FX 770M with 512MB of video memory
Memory and Storage IconMemory and Storage
memoryDDR2 SDRAM, 800 MHz, two SODIMM slots supporting dual channel memory
maximum memoryup to 8, 192 GB
primary storageSATA II hard drives: 160/250 GB 5400 rpm, 160/250/320 GB 7200 rpm, 80 GB Solid State Drive (SSD)
Battery IconBattery
battery8-cell (73 WHr) Lithium-Ion battery
optional batteryHP Extended Life Battery (52 WHr), HP Ultra-Capacity Battery (95 WHr)
Display IconDisplay
display15.4-inch diagonal WSXGA+ WVA (1680 x 1050), 15.4-inch diagonal WUXGA WVA (1920 x 1200)
Ports & Interfaces IconPorts & Interfaces
usb ports4 USB 2.0
other portsRJ-11, RJ-45, headphone jack, microphone jack, docking, Smart AC adapter, VGA, secondary battery connector, 1394a, HDMI, eSATA
media card reader6-in-1

HP EliteBook 8730w Mobile Workstation

Processor and Chipset IconProcessor and Chipset
processorIntel Core Duo (up to 3.06 GHz, up to 6 MB L2 cache), Intel Core Quad-Core (up to 2.53 GHz, up to 12 MB L2 cache)
chipsetMobile Intel PM45 Express Chipset
Graphics IconGraphics
graphicsATI Mobility FireGL V5725 with 256 MB of video memory, NVIDIA Quadro FX 2700M with 512 MB of video memory, NVIDIA Quadro FX 3700M with 1 GB of video memory
Memory and Storage IconMemory and Storage
memoryDDR2 SDRAM, 800 MHz, two SODIMM slots supporting dual channel memory
maximum memoryup to 8, 192 GB
primary storageSATA II hard drives: 160/250 GB 5400 rpm, 160/250/320 GB 7200 rpm, 80 GB Solid State Drive (SSD)
Battery IconBattery
battery8-cell (73 WHr) Lithium-Ion battery
optional batteryHP Extended Life Battery (52 WHr), HP Ultra-Capacity Battery (95 WHr)
Display IconDisplay
display17-inch diagonal WSXGA+ WVA (1680 x 1050), 17-inch diagonal WUXGA WVA (1920 x 1200), 17-inch diagonal WUXGA WVA DreamColor (1920 x 1200)
Ports & Interfaces IconPorts & Interfaces
usb ports4 USB 2.0
other portsRJ-11, RJ-45, headphone jack, microphone jack, docking, Smart AC adapter, VGA, secondary battery connector, 1394a, HDMI, eSATA
media card reader6-in-1
