7 Screw listing
This section provides specification and reference information for the screws and screw locks used in
the computer. All screws listed in this section are available in the Screw Kit, spare part number
494028-001.
Phillips PM3.0×4.0 screw
Color Quantity Length Thread Head diameter
Black 4 4.0 mm 3.0 mm 5.0 mm
Where used: 4 screws that secure the hard drive bracket to the hard drive
Phillips PM3.0×4.0 screw 111
