Page #143 background imageLoading...
Page #143 background image
NOTE: In case of system instability, HP recommends that you print the recovery procedures and save
them for later use.
Backing up your information
Recovery after a system failure is as complete as your most current backup. You should create your
initial backup immediately after software setup. As you add new software and data files, you should
continue to back up your system on a regular basis to maintain a reasonably current backup.
You can back up individual files or folders to an optional external hard drive or to a network drive.
Note the following when backing up:
Store personal files in the My Documents folder, and back it up periodically.
Back up templates stored in their associated programs.
Save customized settings that appear in a window, toolbar, or menu bar by taking a screen shot
of your settings. The screen shot can be a time saver if you have to reset your preferences.
To copy the screen and paste it into a word-processing document:
1. Display the screen you want to save.
2. Copy the screen image:
To copy only the active window, press alt+fn+prt sc.
To copy the entire screen, press fn+prt sc.
3. Open a word-processing document, click Edit > Paste.
The screen image is added to the document.
4. Save the document.
To create a backup using the Windows Backup utility (select models only), follow these steps:
NOTE: Be sure that the computer is connected to AC power before you start the backup process.
NOTE: The backup process may take over an hour, depending on file size and the speed of the
computer.
1. Click Start > All Programs > Accessories > System Tools > Backup.
2. Follow the on-screen instructions.
Performing a recovery
In case of system failure or instability, the computer provides the following tools to recover your files:
Windows recovery tools (select models only): You can use the Windows Backup utility to recover
information you have previously backed up.
Operating System and Driver Recovery discs (included with your computer): You can use the discs
to recover your operating system and programs installed at the factory.
Backup and recovery in Windows XP 133

Table of Contents

Other manuals for HP EliteBook 8730w

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 8730w and is the answer not in the manual?

HP EliteBook 8730w Specifications

HP EliteBook 8530w Mobile Workstation

Processor and Chipset IconProcessor and Chipset
processorIntel Core Duo (up to 3.06 GHz, up to 6 MB L2 cache), Intel Core Quad-Core (up to 2.53 GHz, up to 12 MB L2 cache)
chipsetMobile Intel PM45 Express Chipset (Discrete)
Graphics IconGraphics
graphicsATI Mobility FireGL V5700 with 256MB of video memory, NVIDIA Quadro FX 770M with 512MB of video memory
Memory and Storage IconMemory and Storage
memoryDDR2 SDRAM, 800 MHz, two SODIMM slots supporting dual channel memory
maximum memoryup to 8, 192 GB
primary storageSATA II hard drives: 160/250 GB 5400 rpm, 160/250/320 GB 7200 rpm, 80 GB Solid State Drive (SSD)
Battery IconBattery
battery8-cell (73 WHr) Lithium-Ion battery
optional batteryHP Extended Life Battery (52 WHr), HP Ultra-Capacity Battery (95 WHr)
Display IconDisplay
display15.4-inch diagonal WSXGA+ WVA (1680 x 1050), 15.4-inch diagonal WUXGA WVA (1920 x 1200)
Ports & Interfaces IconPorts & Interfaces
usb ports4 USB 2.0
other portsRJ-11, RJ-45, headphone jack, microphone jack, docking, Smart AC adapter, VGA, secondary battery connector, 1394a, HDMI, eSATA
media card reader6-in-1

HP EliteBook 8730w Mobile Workstation

Processor and Chipset IconProcessor and Chipset
processorIntel Core Duo (up to 3.06 GHz, up to 6 MB L2 cache), Intel Core Quad-Core (up to 2.53 GHz, up to 12 MB L2 cache)
chipsetMobile Intel PM45 Express Chipset
Graphics IconGraphics
graphicsATI Mobility FireGL V5725 with 256 MB of video memory, NVIDIA Quadro FX 2700M with 512 MB of video memory, NVIDIA Quadro FX 3700M with 1 GB of video memory
Memory and Storage IconMemory and Storage
memoryDDR2 SDRAM, 800 MHz, two SODIMM slots supporting dual channel memory
maximum memoryup to 8, 192 GB
primary storageSATA II hard drives: 160/250 GB 5400 rpm, 160/250/320 GB 7200 rpm, 80 GB Solid State Drive (SSD)
Battery IconBattery
battery8-cell (73 WHr) Lithium-Ion battery
optional batteryHP Extended Life Battery (52 WHr), HP Ultra-Capacity Battery (95 WHr)
Display IconDisplay
display17-inch diagonal WSXGA+ WVA (1680 x 1050), 17-inch diagonal WUXGA WVA (1920 x 1200), 17-inch diagonal WUXGA WVA DreamColor (1920 x 1200)
Ports & Interfaces IconPorts & Interfaces
usb ports4 USB 2.0
other portsRJ-11, RJ-45, headphone jack, microphone jack, docking, Smart AC adapter, VGA, secondary battery connector, 1394a, HDMI, eSATA
media card reader6-in-1
