4. Press f11 while the “Press <F11> for recovery” message is displayed on the screen.
5. Follow the on-screen instructions.
Using a Windows Vista operating system DVD (purchased separately)
If you are unable to boot (start up) your computer, you must purchase a Windows Vista operating system
DVD to reboot the computer and repair the operating system. Make sure that your most recent backup
(stored on discs or on an external drive) is easily accessible. To order a Windows Vista operating system
DVD, go to
http://www.hp.com/support, select your country or region, and follow the on-screen
instructions. You can also order the DVD by calling technical support. For contact information, refer to
the Worldwide Telephone Numbers booklet included with the computer.
CAUTION: Using a Windows Vista operating system DVD completely erases hard drive contents and
reformats the hard drive. All files you have created and any software installed on the computer are
permanently removed. When reformatting is complete, the recovery process helps you restore the
operating system, as well as drivers, software, and utilities.
To initiate recovery using a Windows Vista operating system DVD, follow these steps:
NOTE: This process takes several minutes.
1. If possible, back up all personal files.
2. Restart the computer, and then insert the Windows Vista operating system DVD into the optical
drive before the Windows operating system loads.
3. When prompted, press any keyboard key.
4. Follow the on-screen instructions.
5. Click Next.
6. Select Repair your computer.
7. Follow the on-screen instructions.
Backup and recovery in Windows XP
Overview
To protect your information, use the Windows Backup utility (select models only) to back up files and
folders or create recovery points. In case of system failure, you can use the backup files to restore your
computer.
Windows provides the following options:
Backing up individual files and folders
Backing up all files and folders
Scheduling automatic backups
Creating recovery points
Recovering information
NOTE: For detailed instructions, perform a search for these topics in Help and Support.
132 Chapter 8 Backup and recovery

Table of Contents

Other manuals for HP EliteBook 8730w

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 8730w and is the answer not in the manual?

HP EliteBook 8730w Specifications

HP EliteBook 8530w Mobile Workstation

Processor and Chipset IconProcessor and Chipset
processorIntel Core Duo (up to 3.06 GHz, up to 6 MB L2 cache), Intel Core Quad-Core (up to 2.53 GHz, up to 12 MB L2 cache)
chipsetMobile Intel PM45 Express Chipset (Discrete)
Graphics IconGraphics
graphicsATI Mobility FireGL V5700 with 256MB of video memory, NVIDIA Quadro FX 770M with 512MB of video memory
Memory and Storage IconMemory and Storage
memoryDDR2 SDRAM, 800 MHz, two SODIMM slots supporting dual channel memory
maximum memoryup to 8, 192 GB
primary storageSATA II hard drives: 160/250 GB 5400 rpm, 160/250/320 GB 7200 rpm, 80 GB Solid State Drive (SSD)
Battery IconBattery
battery8-cell (73 WHr) Lithium-Ion battery
optional batteryHP Extended Life Battery (52 WHr), HP Ultra-Capacity Battery (95 WHr)
Display IconDisplay
display15.4-inch diagonal WSXGA+ WVA (1680 x 1050), 15.4-inch diagonal WUXGA WVA (1920 x 1200)
Ports & Interfaces IconPorts & Interfaces
usb ports4 USB 2.0
other portsRJ-11, RJ-45, headphone jack, microphone jack, docking, Smart AC adapter, VGA, secondary battery connector, 1394a, HDMI, eSATA
media card reader6-in-1

HP EliteBook 8730w Mobile Workstation

Processor and Chipset IconProcessor and Chipset
processorIntel Core Duo (up to 3.06 GHz, up to 6 MB L2 cache), Intel Core Quad-Core (up to 2.53 GHz, up to 12 MB L2 cache)
chipsetMobile Intel PM45 Express Chipset
Graphics IconGraphics
graphicsATI Mobility FireGL V5725 with 256 MB of video memory, NVIDIA Quadro FX 2700M with 512 MB of video memory, NVIDIA Quadro FX 3700M with 1 GB of video memory
Memory and Storage IconMemory and Storage
memoryDDR2 SDRAM, 800 MHz, two SODIMM slots supporting dual channel memory
maximum memoryup to 8, 192 GB
primary storageSATA II hard drives: 160/250 GB 5400 rpm, 160/250/320 GB 7200 rpm, 80 GB Solid State Drive (SSD)
Battery IconBattery
battery8-cell (73 WHr) Lithium-Ion battery
optional batteryHP Extended Life Battery (52 WHr), HP Ultra-Capacity Battery (95 WHr)
Display IconDisplay
display17-inch diagonal WSXGA+ WVA (1680 x 1050), 17-inch diagonal WUXGA WVA (1920 x 1200), 17-inch diagonal WUXGA WVA DreamColor (1920 x 1200)
Ports & Interfaces IconPorts & Interfaces
usb ports4 USB 2.0
other portsRJ-11, RJ-45, headphone jack, microphone jack, docking, Smart AC adapter, VGA, secondary battery connector, 1394a, HDMI, eSATA
media card reader6-in-1
