Page #144 background imageLoading...
Page #144 background image
Recovering your information
To recover information you previously backed up, follow these steps:
1. If possible, back up all personal files.
2. Click Start > All Programs > Accessories > System Tools > Backup.
The Backup or Restore Wizard opens.
3. Click Restore files and settings, and then click Next.
4. Follow the on-screen instructions.
NOTE: For additional information on initiating a recovery in Windows, perform a search for this topic
in Help and Support.
Recovering the operating system and programs
CAUTION: The recovery process reformats and completely erases the hard drive. All files you have
created and any software installed on the computer are permanently removed. The recovery process
reinstalls the original operating system, software, and drivers. Software, drivers, and updates not
installed by HP must be manually reinstalled.
To recover your operating system and programs, follow these steps:
1. If possible, back up all personal files.
2. Insert the Operating System disc into the optical drive.
3. Shut down the computer.
4. Turn on the computer.
5. Follow the on-screen instructions to install the operating system.
6. After the operating system is installed, remove the Operating System disc and insert the Driver
Recovery disc.
7. Follow the on-screen instructions to install the drivers and programs.
134 Chapter 8 Backup and recovery

Table of Contents

Other manuals for HP EliteBook 8730w

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 8730w and is the answer not in the manual?

HP EliteBook 8730w Specifications

HP EliteBook 8530w Mobile Workstation

Processor and Chipset IconProcessor and Chipset
processorIntel Core Duo (up to 3.06 GHz, up to 6 MB L2 cache), Intel Core Quad-Core (up to 2.53 GHz, up to 12 MB L2 cache)
chipsetMobile Intel PM45 Express Chipset (Discrete)
Graphics IconGraphics
graphicsATI Mobility FireGL V5700 with 256MB of video memory, NVIDIA Quadro FX 770M with 512MB of video memory
Memory and Storage IconMemory and Storage
memoryDDR2 SDRAM, 800 MHz, two SODIMM slots supporting dual channel memory
maximum memoryup to 8, 192 GB
primary storageSATA II hard drives: 160/250 GB 5400 rpm, 160/250/320 GB 7200 rpm, 80 GB Solid State Drive (SSD)
Battery IconBattery
battery8-cell (73 WHr) Lithium-Ion battery
optional batteryHP Extended Life Battery (52 WHr), HP Ultra-Capacity Battery (95 WHr)
Display IconDisplay
display15.4-inch diagonal WSXGA+ WVA (1680 x 1050), 15.4-inch diagonal WUXGA WVA (1920 x 1200)
Ports & Interfaces IconPorts & Interfaces
usb ports4 USB 2.0
other portsRJ-11, RJ-45, headphone jack, microphone jack, docking, Smart AC adapter, VGA, secondary battery connector, 1394a, HDMI, eSATA
media card reader6-in-1

HP EliteBook 8730w Mobile Workstation

Processor and Chipset IconProcessor and Chipset
processorIntel Core Duo (up to 3.06 GHz, up to 6 MB L2 cache), Intel Core Quad-Core (up to 2.53 GHz, up to 12 MB L2 cache)
chipsetMobile Intel PM45 Express Chipset
Graphics IconGraphics
graphicsATI Mobility FireGL V5725 with 256 MB of video memory, NVIDIA Quadro FX 2700M with 512 MB of video memory, NVIDIA Quadro FX 3700M with 1 GB of video memory
Memory and Storage IconMemory and Storage
memoryDDR2 SDRAM, 800 MHz, two SODIMM slots supporting dual channel memory
maximum memoryup to 8, 192 GB
primary storageSATA II hard drives: 160/250 GB 5400 rpm, 160/250/320 GB 7200 rpm, 80 GB Solid State Drive (SSD)
Battery IconBattery
battery8-cell (73 WHr) Lithium-Ion battery
optional batteryHP Extended Life Battery (52 WHr), HP Ultra-Capacity Battery (95 WHr)
Display IconDisplay
display17-inch diagonal WSXGA+ WVA (1680 x 1050), 17-inch diagonal WUXGA WVA (1920 x 1200), 17-inch diagonal WUXGA WVA DreamColor (1920 x 1200)
Ports & Interfaces IconPorts & Interfaces
usb ports4 USB 2.0
other portsRJ-11, RJ-45, headphone jack, microphone jack, docking, Smart AC adapter, VGA, secondary battery connector, 1394a, HDMI, eSATA
media card reader6-in-1
