Phillips PM2.5×9.0 captive screw
Color Quantity Length Thread Head diameter
Black 5 9.0 mm 2.5 mm 5.0 mm
Where used: (1) One captive screw that secures the optical drive to the computer (screw is secured by
a C-clip)
Where used: (2) Four captive screws that secure the keyboard to the computer (screws are secured
by C-clips)
112 Chapter 7 Screw listing
